Irizar Heavy Industries Inc. is a Canadian company based in Edmonton. We take pride in manufacturing the world's largest Self Aligned Welding Rotators and owning the world's largest stock.



Capacity:

The vessel sits on four wheels: Full Load Capacity
Vessel Diameter Range is from 3,110 up to 8,000 mm.
Power Rotator Max Rotation Capacity: 500 MT
Power Rotator Max Load Capacity: 250 MT
Idler Rotator Max Load Capacity: 250 MT

The vessel sits on two bottom wheels: Half Load Capacity
Vessel Diameter Range is from 1,800 up to 3,100 mm
Power Rotator Max Rotation Capacity: 250 MT
Power Rotator Max Load Capacity: 125.00 MT
Idler Rotator Max Load Capacity: 125.00 MT

Specifications:

Variable Speed: From 100 up to 1,000 mm/minute
Remote Control Box with 6 m cable:
Forward/Stop/Reverse/Variable speed adjustment with digital display in mm/min
Power: 7.50 kw @ 2
Wheel Diameter: 800 mm
Wheel Width: 300 mm
Estimated Weight: 28.00 MT
Warranty: One year
Operation Manual & Electric Diagram: Included

  Delivery Time:


Within Canada: Three to five business days
USA & US-Mexican border: One week
Latino America: Four weeks
World-Wide: Five to six weeks
