Irizar Heavy Industries Inc., based in Edmonton, Alberta, Canada, designs and manufactures heavy-duty Tank & Vessel Roller Beds for the fit-up, assembly, support, and rotation of tanks, pressure vessels, pipes, and other large cylindrical workpieces. Roller Bed systems are custom designed according to the required load capacity, workpiece diameter, length, rotation speed, and roller configuration.
Gallery
Specifications
1. Maximum load and rotation capacity (MT):
2. Workpiece diameter range, min-max. (m):
3. Workpiece maximum length, "L" (m):
4. Configuration:
+ Two power rollers synchronized with “L/2” meters length + two idler rollers
+ Two power rollers synchronized with “L/4” meter length + three sets of idler rollers
5. Rotation speed:
+ 100 to 1,000 mm/minute
+ 200 to 2,000 mm/minute
6. Rollers:
+ Steel
+ Covered with polyurethane (PU)
7. Adjust center-to-center between rollers:
+ With bolts and nuts
+ Motorized adjustment
8. Control Box:
+ 6 m wire control
+ 60 m wireless control
9. Electric Input Power:
+ 480 V, 60 Hz, 3P
+ 380 V, 50 Hz, 3P
