Specifications:
Power Rotator Max Rotation Capacity: 150 MT
Power Rotator Max Load Capacity: 75 MT
Idler Rotator Max Load Capacity: 75 MT
Vessel Diameter Range: From 800 mm up to 7,800 mm
Variable Speed: From 100 up to 1,000 mm/minute
Remote Control Box with 6 m cable:
Forward/Stop/Reverse/Variable speed adjustment with digital display in mm/min
Power: 4.00 kW @ 2
Wheel Diameter: 500 mm
Wheel Width: 260 mm
Estimated Weight: 5.50 MT
Warranty: One year
Operation Manual & Electric Diagram: Included
Notes:
1. Six sets of Welding Rotators Model WR 150 in stock.
2. Four sets of WR 150: Under construction, available July 2024.
3. Two sets of WR 150 (two powers + two idlers): 300 MT of load and rotation capacity.
4. Four new Idler Rolls Model IR 150 (75 MT each): Available for extra support
5. Stock: Six sets
6. Fabrication: Four sets available July 2024
Delivery Time:
Within Canada: Three to five business days
USA & US-Mexican border: One week
Latino America: Four weeks
World-Wide: Five to six weeks
