Irizar PR 5 Pipe Rotators are 5 MT capacity pipe welding rotators designed to support, position, and rotate pipes and other cylindrical workpieces during welding, fabrication, assembly, and inspection. The PR 5 includes one power rotator and one idler rotator, providing a combined maximum loading and rotation capacity of 5 MT (11,000 lbs). Pipe Rotators provide variable-speed rotation and come as a complete set of one power rotator and one idler rotator. Their compact and heavy-duty design makes them well-suited for pipe fabrication shops, production lines, and automated or manual welding applications.
Available in Stock:
Models from 1 to 5 MT: PR 1 | PR 3 | PR 5
Specifications
- Load and rotation capacity: 5 MT
- Pipe Diameter Range: From 50 up to 600 mm
- Variable Speed: From 100 up to 1,000 mm/minute
- Control Box: Forward/Stop/Reverse/Speed Adjustment
- Power: 0.75 kW
- Roller Wheels: Heavy-duty rubber
- Wheel Diameter: 200 mm
- Wheel Width: 50 mm
- Estimated Weight: 820 Kilos
- Warranty: One year
- Operation Manual & Electric Diagram: Included
Gallery
Delivery Time
Canada: 3–5 business days
USA & U.S.–Mexico Border: Approximately 1 week
Latin America: Approximately 4 weeks
Worldwide: Approximately 5–6 weeks
