Irizar Heavy Industries Inc. proudly manufactures tank dismantling jacks designed to remove existing tanks safely without the need for a crane. These jacks are suitable for dismantling both API field-erected welded tanks and bolted tanks. These jacks are used for lowering (not for lifting). The estimated dismantling time for lowering a 19-inch tank is approximately as follows: Number of jacks x 1.50 minutes. One operator with a helper is required for the operation. Labour for setting up the jacks, cutting rings, or welding, lifting and pulling hooks is not included.
Certifications, Test & Safety
Frequently Asked Questions (FAQ]
Knowledge Base [KB]
Irizar Heavy Industries Inc. has developed unique and sophisticated software that calculates the number of jacks needed and their respective capacities to ensure safe lifting. The software considers the tank's lifting weight and other factors, such as tank diameter and height, roof weight, snow, wind, and seismic loads.
Interested parties seeking a quote must accurately provide the tank specifications listed below. This information is essential for Irizar to determine the correct number of jacks needed for safely lifting the tank. If any information changes, please notify us immediately.
Specifications:
Working capacity: 6 MT
Jack type: Double action
Minimum tank diameter: 5.0 m
Minimum shell thickness: 3.175 mm (1/8”)
Maximum shell height: 2.50 m
Minimum-Maximum arc distance between jacks: 1.5 to 3.0 m
Jack unitary descent: 500 mm/stroke
Warranty: One Year
Jack's weight: 86 kilos
Accessories weight: 260 kilos
Packing weight: 40 kilos
Total weight: 386 kilos/jack
Operation Manual: Included
Hydraulic Power Pack:
20 HP, Max 65 jacks
Tank capacity: 800 litres
Pump flow: 96 LPM
Working pressure: 2,500 PSI
Weight: 600 kilos
Input Power: 240/60/3 or 380/50/3
Electric diagram: Included
Training:
It is available in our Wetaskiwin, Alberta Training Facility in a real-life environment or as an online course; both come with 24/7 WhatsApp Tech Support for one year. The course is designed to be completed within one day and can accommodate up to three operators. Completion of this course is required to receive a warranty.
Delivery Time:
