Irizar Heavy Industries Inc. is a Canadian company based in Edmonton. We take pride in manufacturing Cradle Weld Positioners. These devices move the workpiece under the welding process equipment, whereas Welding Manipulators move the equipment over the workpiece. The Positioner offers powered 360° variable-speed rotation and table tilt, ranging from horizontal to 120°. Cradle Welding Positioners are designed for lifting, tilting, and turning extra-large and wide workpieces. They are also known as Gear-Driven Positioners, Tilt/Turn Positioners, and Posicionador de Soldadura.



Load Capacity:

60.00 MT @ 1800 mm GC
54.00 MT @ 2000 mm GC
49.00 MT @ 2200 mm GC
45.00 MT @ 2400 mm GC
41.50 MT @ 2600 mm GC
38.50 MT @ 2800 mm GC
36.00 MT @ 3000 mm GC



Specifications:

Eccentricity: 300 mm
Rotation speed: From 0.05 to 0.50 RPM
Tilt speed: From 0.01 to 0.10 RPM
Table diameter: 3000 mm with extended arms 6,000 mm
Table with “T” shaped channels @ 45 degrees
Control Box: Forward/Stop/Reverse/Wireless Speed Adjustment with digital display
Max work piece diameter @ 90 degrees tilt: 5,500 mm
Tilt Angle: 0 to 90 degrees
Power Rotation: 18.50 kW
Power Tilt: 11.00 kW @ 2
Estimated Weight: 65.00 MT
Warranty: One year
Operation Manual & Electric Diagram: Included



Delivery Time:
